Also the button Fault reset is not blocked at all and buttons Start and Stop in MAN mode are not
blocked.
Remote OFF
If closed, iL is switched to OFF mode (there are four modes OFF-MAN-AUT-TEST). When opens
controller is switched back to previous mode.
Hint:
This binary input should be connected to schedule timer switch, to avoid start of engine.
Remote MAN
If the input is active, MAN mode is forced to the controller independently on the position of the MODE
selector.
Remote AUT
If the input is active, AUTO mode is forced to the controller independently on the position of the MODE
selector. If another of „remote“ inputs is active, then the REMOTE AUT input has the lowest priority.
Remote TEST
If closed, IL-NT is switched to TEST mode (there are four modes OFF-MAN-AUT-TEST). When opens
controller is switched back to previous mode.
Rem TEST OnLd
Affects the behaviour in TEST mode. When input is closed, the controller automatically transfers load
from the mains to the gen-set. Setpoint AMF Settings: ReturnFromTEST must be set to MANUAL.
Load is automatically transferred back to the mains when any gen-set shut down protection activates.
In case AMF Settings: ReturnFromTEST is set to AUTO, then only gen-set is started, but MCB is not
opened and GCB is not closed, except there is a Mains fail.
For more details see description of the setpoint AMF Settings: ReturnFromTEST.
RemControlLock
If the input is active, setpoints writing or command sending from the external terminal is disabled.
EF Prot Test
If the binary input is activated (edge 0 -> 1 on the binary input is detected) then EF Prot Test is
executed. This function is the same as the one which can be executed using EF Prot Test command
in Man Operations group or using controller buttons combination. For more details about these options
see Man Operations: EF Prot Test and Earth Fault Protection Test description.
Hint:
Any time binary input EF PROT TEST is activated “Wrn EFProtTest” message appears on controller
display to inform operator that the protection was activated manualy and also that the binary input EF
PROT TEST remains in active position. The message is active whole time the binary input is kept in
active position even if Fault Reset acknowledging the Earth Fault Sd protection is pressed. Wrn
EFProtTest message has only informative character and it is not recorded in the controller history.
Emergency MAN
If the input is activated the controller behaves like when switched to OFF Mode. Opens all binary
outputs. There is one exception – STOP SOLENOID doesn’t activate on this transition.
Detection of "running" engine and subsequent alarm message "Sd Stop Fail" is blocked.
The controller shows “EmergMan” state and the engine can not be started.
Generator current and power measurement is active in this mode, regardless of the actual state of the
engine.
