History file
InteliLite NT stores a record of each important event into the history file. The history file seats 117
records. When the history file is full, the oldest records are removed.
Hint:
To force history download in LiteEdit (direct,modem or Internet) open History window and select
History | Read history command.
Record structure
Abbreviation
Historical value
Num
Number of historical event
Reason
Event specification
Date
Date of historical event in format DD/MM/YY
Time
Time of historical event in format HH:MM:SS
Mode
Controller’s mode
RPM
Engine speed
Pwr
Generator active power
PF
Generator PF
LChr
Character of the load
Gfrq
Generator frequency
Vg1
Generator voltage L1
Vg2
Generator voltage L2
Vg3
Generator voltage L3
IL1
Generator current L1
IL2
Generator current L2
IL3
Generator current L3
EF
Earth fault current
Vm1
Mains voltage L1
Vm2
Mains voltage L2
Vm3
Mains voltage L3
Mfrq
Mains frequency
UBat
Battery voltage
OilP
IL-NT Analog input 1 value ( default Oil pressure)
EngT
IL-NT Analog input 2 value ( default Engine temperature)
FLvl
IL-NT Analog input 3 value ( default Fuel Level)
BIN
Binary inputs IL-NT
BOUT
Binary outputs IL-NT
FC*
ECU alarm FailureCode
FMI*
ECUalarm Failure Mode Identifier
AIM1*
IG-IOM, IGS-PTM Analog input 1 value (when configured IG-IOM, IGS-PTM)
AIM2*
IG-IOM, IGS-PTM Analog input 2 value (when configured IG-IOM, IGS-PTM)
AIM3*
IG-IOM, IGS-PTM Analog input 3 value (when configured IG-IOM, IGS-PTM)
AIM4*
IG-IOM, IGS-PTM Analog input 4 value (when configured IG-IOM, IGS-PTM)
BIM*
IG-IOM, IGS-PTM Binary inputs (when configured IG-IOM, IGS-PTM)
BOM*
IG-IOM, IGS-PTM Binary outputs (when configured IG-IOM, IGS-PTM)
BIOE*
Extension plug-in module inputs and/or outputs
*Depends if enabled in configuration (see more details in LiteEdit-4.4-Reference Guide.pdf)
