Support of communication with MTU ADEC without SAM
Values read from ADEC:
Value in controller
CAN ID
MUX
RPM
1000
1
Cool Temp ECU
1005
0
IntakeTemp ECU
1005
5
Oil Press ECU
1001
0
BoostPress ECU
1001
23
Oil Temp ECU
-
-
Fuel Rate ECU
1004
18
Run Hours
1004
14
ECU YellowLamp
1000
9
ECU RedLamp
1000
13
Actual Failure Codes*
1002
24
* for list of fault codes see:
ECU list – Pramac-1.0 new features list
Values written to ADEC:
Value in controller
CAN ID
MUX
ECU SpeedAdj setpoint
1019
0
Starter
1019
21
Stop solenoid
1019
7
Fault reset
1019
8
Nominal Freq (50 / 60)
1019
24
Sd Override
1019
3
x Yellow and Red Lamp behaviour
Yellow lamp is indicated in controller alarm list as “ECU YellowLamp”. Red lamp is indicated in
controller alarm list as “ECU RedLamp” and it causes activation of shutdown protection. So if
the ECU stops the engine and activates red lamp, the controller only shows red lamp alarm
but doesn’t show undervoltage and underspeed alarms.
x Control signals for MTU ADEC with SAM over CAN
Signal
PGN
SPN
Source value
Override
FEF1
1237
Sd Override input
Alarm Reset
FF2D
Fault reset
50/60Hz
FF2D
setpoint Nominal Freq
Start
FF2D
Starter
Stop
F001
Stop pulse
Speed demand
0080
898
ECU SpeedAdj setpoint
x Running hours reading from ECU
The controller doesn’t display invalid values (if the ECU is sending non-valid running hours
then the controller switches to it’s own hours measurement).
x Phone number modification – TelNo/Addr Ch1/2/3/4 setpoints
Phone number modification is completed when two space symbols one after another are
inserted and the second space is confirmed by pressing ENTER button.
