Value measured on analog input 1 is lower
than AI1 Wrn setpoint.
Value measured on analog input 1 is lower
than AI1 Sd setpoint.
Value measured on analog input 2 is
greater than AI2 Wrn setpoint.
Value measured on analog input 2 is
greater than AI2 Sd setpoint.
Value measured on analog input 3 is
greater than AI3 Wrn setpoint.
Value measured on analog input 3 is
greater than AI3 Sd setpoint.
Battery voltage is out of limits given by Batt
Undervolt/Batt OverVolt setpoints.
Warning alarm configurable on the input of
IG-IOM/IGS-PTM.
Shutdown alarm configurable on the input
of IG-IOM/IGS-PTM.
Configurable Warning, Shutdown or BOC
alarms on the inputs of IL-NT.
If the input Emergency Stop is opened
shutdown is immediately activated.
The protection is active if the output Sd
Override is closed.
Sd Gen Lx > V
(Where x=1,2,3)
The generator voltage is out of limits given
by Gen >V Sd setpoints.
BOC Gen Lx < V
(Where x=1,2,3)
The generator voltage is out of limits given
by Gen <V BOC setpoints.
The generator voltage is unbalanced more
than the value of Volt Unbal Sd setpoint.
The generator frequency is out of limits
given by Gen >Freq Sd setpoints.
The generator frequency is out of limits
given by Gen <Freq BOC setpoints.
Generator params are not OK, voltage or
frequency are out of limits.
The generator current is unbalanced (there
is generator current asymetry).
Generator current exceeds the limit for
IDMT protection given by Nominal current
and Amps IDMT Del setpoints.
The load is greater than the value given by
Overload setpoint.
Short circuit of generator.
This alarm is activated when Eart Fault
value exceeds Earth Fault Sd limit for at
least Earth Fault Del period.
The protection comes active if the speed is
greater than Overspeed setpoint.
