Installing IL-NT-AOUT8 module is similar to installing RS 232 module. The difference is that IL-NT-
AOUT8 fits to “extension module” slot and after installing IL-NT-AOUT8 you do not put back the small
cover.
PC Installation Suite consist a set of prepared converting curves for basic usage of PWM outputs with
automotive gauges.
IL-NT-AOUT8 module:
Typical wiring:
