InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 43
AMF26-P-2.4 Reference Guide.pdf
Config: Selection between Analog, Binary Tri-state input.
“Analog” – resistor sensor is connected to Analog input.
“Binary” – open/close contact is connected between Analog input and COM terminal of Analog inputs.
Analog input detects only open/close state.
“Tri-state” – open/close contact is connected parallel to one of two serial resistors between Analog
input and COM terminal of Analog inputs.
Set to: Analog
Alarm Properties: Selection between different direction of protection – Under Limit, Over Limit or
combination with Fail sensor.
“Engine running only” – check this setting if you wish to active protection on analog input only while
engine is running, not, when it stops.
Set to: Over Limit
Contact type: selection of polarity only when analog input is configured as Binary or Tri-state. When
is analog input configured as analog this setting has no sense.
„NC“ – polarity of binary or tri-state input
„NO“ – polarity of binary or tri-state input
Sensor: selection of sensor characteristic
„Unused input“ - when Analog input is not used. On the IL-NT screen is displayed „####“ value, no
alarm is detected.
Default user curves predefined on AI1 – AI3:
„VDO 10 Bar“ – VDO pressure sensor
„VDO 40-120 °C“ – VDO temperature sensor
„VDO level %“ – VDO level sensor
Set to: VDO 40-120 °C
When you choose the predefined or user curve the Sensor Name, Dim and Resolution are setted
automaticly according to curve, user modification is possible.
Sensor Name: Name of used sensor, up to 14 letters can be used.
Dim: Name of measured unit (Bar, °C, %, …), up to 4 letters can be used.
Resolution: setting of resolution of measured value.
„0“ - e.g. 360 kPa, 100%, 50 qC
„1“ – e.g. 360,0 kPa
„2“- e.g. 360,00 kPa
„3“ - e.g. 360,000 kPa
Set to: 1
When Analog input configuration is finished set the setpoints AI1 Wrn, AI1 Sd, AI1 Del in Engine
Protect group.
Each Analog input has separate triplet of setpoints: Wrn level, Sd level, AI del. Names of these
setpoints are fix defined
Number of decimal points of Wrn level and Sd level is the same as the configured number of decimal
points of measured value.
