InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 52
AMF26-P-2.4 Reference Guide.pdf
Hint:
There is an analogical function implemented in Deutz EMR2 (ECU), where the information about
preheating is not shared through binary input but through CAN bus and J1939 protocol. The Deutz
EMR2 Preheating function is supported in the controller only in case EMR2Preheating setpoint is set
to ENABLED and Deutz EMR2 ECU is configured.
AltCfgSwitch A
If the input is closed and setpoint Alternate Cfg: Config Switch is set to BinSelect, the combination of
AltCfgSwitch inputs defines what Alternate Cfg group (of gen-set nominal values) is active.
AltCfgSwitch B
If the input is closed and setpoint Alternate Cfg: Config Switch is set to BinSelect, the combination of
AltCfgSwitch inputs defines what Alternate Cfg group (of gen-set nominal values) is active.
AltCfgSwitch A
0
1
0
1
AltCfgSwitch B
0
0
1
1
Chosen Configuration group
Basic Settings*
Configuration1
Configuration2
Configuration3
*In case of 0,0 combination values are not transfered between Basic Settings and Alternate Cfg groups.
For more details about Alternate Configuration see Alternate Cfg group setpoints description.
There are two new logical binary inputs Remote Start and Remote Stop
REMOTE START:
- active only in AUT mode
- when REMOTE START activated gen-set is started and loaded
- when REMOTE START deactivated in case Mains is OK, Load is transferred back to Mains, not
immediately, but after AMF settings: MainsReturnDel (this is valid only in case REMOTE START is
deactivated before AMF settings: MainsReturnDel is started)
- when REMOTE START deactivated in case Mains is NOT OK, Load is not transferred
REMOTE STOP
- active only in AUT mode
- REMOTE STOP only blocks the gen-set starts caused by Mains fail
- gen-set is started in case REMOTE STOP is active in following cases:
- SD OVERRIDE is active (the system behaves as the the REMOTE STOP is not active)
- REM START/STOP is active (but even in case of MainsFail GCB is not closed)
- REMOTE START is active (the system behaves as the the REMOTE STOP is not active)
- in case of Mains fail Start Del is counted and MCB state is set according to AMF Settings: MCB
Opens On
Nom Freq 60Hz
If the input is closed, Nominal Freq is switched from its current value (Nominal Freq A) to Nominal
Freq = 60Hz. At the same moment Nominal RPM is switched from its current value (Nominal RPM A)
to new value (Nominal RPM B) which is calculated according to the following equation.
Nominal RPM B = Nominal RPM A * 60 / Nominal Freq A
When the input is active it is not possible to change Nominal Freq and Nominal RPM parameters
values, neither from LiteEdit nor from controller display.
