seconds period after reaching Starting RPM. A Start Fail protection occurs if the RPM drop below
2RPM during idle.
Hint:
Connect Binary output Idle/Nominal to speed governor to switch the speed: opened = IDLE,
closed=NOMINAL. If the IDLE contact is not supported on the governor, set the Idle Time
nevertheless to minimum 5s to avoid Underspeed possibly caused by instability of the engine short
after start.
Air Valves
Closes together with Prestart. Opens after the engine is stopped.
Stopped engine conditions: RPM = 0, Engine Params: Starting Oil P, D+ (when enabled).
Alarm
The output closes if :
x any alarm comes up or
x the gen-set malfunctions
The output opens if
x FAULT RESET is pressed
The output closes again if a new fault comes up.
Horn
The output closes if:
x any alarm comes up or
x the gen-set malfunctions
The output opens if:
x FAULT RESET is pressed or
x HornResButton binary input is activated or
x Max time of HORN is exceeded (Horn Timeout)
The output closes again if a new fault comes up.
Emergency Stop
The output closes if:
x Emergency Stop is activated
The output opens if:
x alarm is not active and
x FAULT RESET is pressed
COMPARATOR OUT
The output is activated at the moment when Comparator ON limit is reached and is deactivated when
Comparator OFF limit is reached
GCB Close/Open
The output controls the generator circuit breaker.
Hint:
Supposed time to close (reaction time) of GCB is 0,1 sec.
GCB ON Coil
The output activates Generator Circuit Breaker coil.
