INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 160
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
DSCP-Based QoS
This page allows you to configure the basic QoS DSCP based QoS Ingress Classification settings
for all switches.
Object Description
DSCP Maximum number of supported DSCP values is 64.
Trust Controls whether a specific DSCP value is trusted. Only frames with trusted DSCP values are
mapped to a specific QoS class and Drop Precedence Level. Frames with untrusted DSCP values are
treated as a non-IP frame.
QoS Class QoS class value can be any of (0-7)
DPL Drop Precedence Level (0-1)
Apply Click to apply changes.
Reset Click to revert to previous values.
