INS_CNGE3FE8MS[POE][HO] Rev. 11.7.17 PAGE 66
INSTRUCTION MANUAL CNGE3FE8MS[POE][HO]
TECH SUPPORT: 1.888.678.9427
Object Description
Shutdown Specify the port shut down operation of this port. The allowed values are: Enabled: If a frame is
received on the port, the port will be disabled. Disabled: Port shut down is disabled.
The default value is “Disabled”.
Note: The shutdown feature only works when the packet length is less than 1518(without VLAN
tags).
State Specify the port state of this port. The allowed values are:
Enabled: To reopen ports by changing the volatile port configuration of the ACL user module.
Disabled: To close ports by changing the volatile port configuration of the ACL user module.
The default value is “Enabled”.
Counter Counts the number of frames that match this ACE.
Apply Click to apply changes.
Reset Click to revert to previous values.
Refresh Click to refresh the page.
Clear Click to clear the counters.
