CONTROLLER
OPERATION
58
A
2.1.7.2 Operation of the 3-Pedal
Footswitch (C9863)
Operation of the footswitch when using a
MicroChoice Sagittal Saw (5020-022),
Reciprocating Saw (5020-023), Oscillator
Handpiece (5020-024), or E9015 Cranial
Perforator Drive:
NOTE: There is no oscillate or reverse
mode for these handpieces.
1. Depress either the left or right pedal to
activate the handpiece.
2. The center pedal is inoperative using these
handpieces.
Operation of the footswitch when using a
MicroChoice Elite High Speed Drill
(5020-025), Medium Speed Drill (5020-021),
or Low Speed Drill (5020-026) and the
CoolFlex High Speed Drill (E9010):
1. Depress the right pedal to activate
the handpiece in the forward
direction.
2. Depress the left pedal to activate
the handpiece in the reverse
direction. A brief beep will
indicate reverse direction when the
handpiece is initially activated.
3. The center pedal is inoperative using these
handpieces.
