This programming means that the Up movement will be inhibited when the Inhibit 4 input is in Band 0, i.e. one end of recline
travel, and that the Down movement will be inhibited when the Inhibit 4 input is in Band 3, i.e. the other end of the recline
travel. Referring the Band diagram above, it can be seen that by programming Inhibit 4 Upper Level Threshold and Inhibit 4
Lower Level Threshold, then the actual angular range of the recline mechanism is adjusted.
INHIBITS – GLOBAL
13.1 DISABLE INHIBIT 2 IN DRIVE
This sets whether the PM Inhibit 2 input is interrogated just at entry into Drive Mode or constantly during Drive Mode.
The programmable options are Yes and No.
If set to Yes, the input will only be interrogated at entry into Drive Mode. An example of when this function may be useful is if a
tilt-sensor is used that could be inadvertently operated when driving over rough terrain. By employing this function, an inhibit
will only be applied if Drive Mode is entered with the seat in a genuinely tilted position.
If set to No, the input will be interrogated constantly during Drive Mode, i.e. normal inhibit operation.
13.2 DISABLE INHIBIT 3 IN DRIVE
This sets whether the PM Inhibit 3 input is interrogated just at entry into Drive Mode or constantly during Drive Mode.
The programmable options are Yes and No.
If set to Yes, the input will only be interrogated at entry into Drive Mode. An example of when this function may be useful i s if a
tilt-sensor is used that could be inadvertently operated when driving over rough terrain. By employing this function, an inhibit
will only be applied if Drive Mode is entered with the seat in a genuinely tilted position.
If set to No, the input will be interrogated constantly during Drive Mode, i.e. normal inhibit operation.
INHIBITS - INPUTS – PM
13.13 LOWER LEVEL THRESHOLD
This sets the level of the threshold between Band 0 and Band 1 for a particular Inhibit Input (Inhibit 2 or Inhibit 3) on the Power
Module. See Inhibits Explained for more details on Power Module inhibits and Bands.
The programmable range is 0% to 100% in steps of 1%.
13.4 MIDDLE LEVEL THRESHOLD
This sets the level of the threshold between Band 1 and band 2 for a particular Inhibit Input (Inhibit 2 or Inhibit 3) on the Power
Module. See Inhibits Explained for more details on Power Module inhibits and bands.
The programmable range is 0% to 100% in steps of 1%.
13.5 UPPER LEVEL THRESHOLD
This sets the level of the threshold between Band 2 and band 3 for a particular Inhibit Input (Inhibit 2 o r Inhibit 3) on the Power
Module. See Inhibits Explained for more details on Power Module inhibits and bands.
