Drive means that the Power Module is the active Output Device and Seating means that the Seating Module is the active Output
Device.
Because OBP assumes a Mode, then if OBP is required one of the Modes, normally Mode 8, should be set to Programming.
There are some other Output Device identifiers that a currently defined, such as Environmental , these are for use with future
planned Output Modules.
The settings Output 3 to Output 7 are unique identifiers that can be assigned to Input/Output Modules (IOMs).
NOTE:
The number of unique identifiers is unlimited meaning any number of specialist modules can be supported.
6 SPEEDS
6.1 MAXIMUM FORWARD SPEED - (FWD SPEED MAX)
Sets the forward driving speed of the wheelchair when the joystick is deflected full ahead and the speed setting is at maximum
(all 5 bars illuminated).
Programmable range is 0 to 100% in steps of 1%.
6.2 MINIMUM FORWARD SPEED - (FWD SPEED MIN)
Sets the forward driving speed of the wheelchair when the joystick is deflected full ahead and the speed setting is at minimum
(just 1 bar illuminated).
Programmable range is 0 to Maximum Forward Speed in steps of 1%.
NOTE:
It is not possible to set the value of Minimum Forward Speed higher than the value of Max. Forward Speed.
6.3 MAXIMUM REVERSE SPEED - (REV SPEED MAX)
Sets the reverse driving speed of the wheelchair when the joystick is deflected to full reverse and the speed setting is at
maximum (all 5 bars illuminated).
Programmable range is 0 to 100% in steps of 1%.
6.4 MINIMUM REVERSE SPEED - (REV SPEED MIN)
Sets the reverse driving speed of the wheelchair when the joystick is deflected to full reverse and the speed setting is at
minimum (just 1 bar illuminated).
Programmable range is 0 to Maximum Reverse Speed in steps of 1%.
NOTE:
It is not possible to set the value of Minimum Reverse Speed higher than the value of Max. Reverse Speed.
