5.1 MODE NAME
This is a 20 character text string that will appear on the JSM LCD screen to indicate the active Mode. See Configuration
Explained for more details.
NOTE:
Although there are options to change the Mode Names for Drive and Seating Modes, these text strings will not appear on the
standard JSM screens. These text options are reserved for future Input Devices.
5.2 INPUT
This sets the data that the Input Device transmits to the Output Device for each mode. See Configuration Explained for more
details.
The programmable options are in the form of a drop-down menu, as shown in the following diagram.
Drive provides data that is appropriate for driving the wheelchair and should always be used for Drive mode, i.e. when the
Power Module is the active Output Device.
Seating provides data that is appropriate for controlling the seating of the wheelchair and should always be used for Seating
Control mode, i.e. when an ISM, or equivalent, is the active Output Device.
Raw provides basic joystick x and y data, but scaled for deadband, throw and orientation. Additionally, 'raw' button operatio ns
are also transmitted. This setting can be used for any other Output Module types.
Programming sets which Mode is reserved for OBP. This is usually Mode 8.
5.3 OUTPUT
This sets the Output Device that is active for the Mode. See Configuration Explained for more details.
The programmable options are in the form of a drop-down menu, as shown in the following diagram
