CHAPTER 8 – ISM-8
1 INTRODUCTION
The R-net Intelligent Seating Module-8 (ISM-8) is an actuator module that offers advancements over the existing R-net ISM. The
ISM-8 allows simultaneous channel operation with independent direction control.
2 INSTALLATION
An ISM-8 can be fitted at any point within a R-net Control System. See following diagram.
CAUTION:
It is possible to set up a Control System so that it is unsuitable for some users or even some vehicles. For all of the above
reasons it is important that you contact Curtiss-Wright if you have the slightest doubts or if you need any advice on
programming.
WARNING:
Programming and diagnostics should only be conducted by healthcare professionals with in-depth knowledge of Curtiss-
Wright electronic Control Systems. Incorrect programming could result in an unsafe setup of a vehicle for a user. Curtiss-
Wright accept no liability for any losses of any kind if the programming of the Control System is altered from the factory-
preset values.
