24 | R-net Technical Manual | Chapter 1 - Operation
6.2.2 MOTOR TEMPERATURE
This symbol is displayed when the control system has intentionally reduced the power to the
motors, in order to protect them against heat damage.
6.2.3 CONTROL SYSTEM TEMPERATURE
This symbol is displayed when the control system has intentionally reduced its own power, in
order to protect itself against heat damage.
6.3 MAIN SCREEN AREA
Drive Screen
6.3.1 PROFILE NAME
This is a text string that displays the name of the currently selected Profile. The name is
programmable. Refer to the programming section for details.
6.3.2 CLOCK
This displays the current time in a numeric format.
The clock is user adjustable. Adjustable options are:
 Visibility, whether the clock is displayed on screen.
 The display format, 12 or 24 hour.
 The time, the user can adjust the time.
These adjustments are made within the Settings Menu. Refer to section 8 for details.
6.3.3 SPEED DISPLAY
This gives a proportional display of the wheelchairs speed. The Arc begins at 0%
and has a programmable maximum. The programmable parameter is Max
Displayed Speed. Refer to the Programming Chapter.
