8 LATCHED
8.1 LATCHED DRIVE - (DRIVE)
This sets the type of latched drive of the wheelchair.
The programmable options are in the form of a drop-down menu as shown in the following diagram.
If set to Off, there will be no latched drive.
If set to Step, the latched drive will be step type, but in the forwards direction only.
If set to Step reverse, the latched drive will be step type in both forwards and reverse.
Stepped drive is when short deflections of the joystick step up or down the latched drive speed of the wheelchair.
If set to Cruise, the latched drive will be cruise type, but in the forwards direction only.
If set to Cruise reverse, the latched drive will be cruise type in both forwards and reverse.
Cruise drive is when the wheelchair accelerates while the joystick is deflected, then, when the joystick is released the drive
continues at the achieved speed.
NOTE:
If any Profile has latched drive set, then an Emergency Stop Switch must be fitted to the system via the Profile jack socket on
the Joystick Module. If it is required for the system to operate without an Emergency Stop switch, this can be achieved via
the parameter, Emergency Stop Switch.
WARNING:
Curtiss-Wright accepts no liability for losses of any kind resulting from the use of a wheelchair with latched drive or actuator
operation and with no normally closed Emergency Stop Switch fitted.
8.2 LATCHED ACTUATORS - (ACTS)
This sets whether the seating functions are latched in operation.
The programmable options are Yes and No.
If set to Yes, then seating control will be latched in operation. i.e. a short joystick deflection will start seat movement.
If set to No, then the seating control will not be latched in operation.
NOTE:
