205 | R-net Technical Manual | Chapter 12 – Specifications
Curtiss-Wright | PG Drives Technology
CHAPTER 12 – SPECIFICATIONS
1 ELECTRICAL SPECIFICATIONS
Supply Voltage: 24Vdc
Operating Voltage: 16Vdc to 35Vdc
Peak Voltage: 35Vdc
Reverse Battery Protection: -40Vdc
PWM Frequency: 20kHz ± 0.5%
Brake Voltage: 12/24Vdc
Brake Current: 200µA min.
1A max.
Charger Connector: Use only Neutrik NC3MX
Battery Charging Current: 12Arms max.
Maximum Drive Current:
R-Net 80 80A
R-Net 90 90A
R-Net 120 120A
Indicator Outputs 42W per side
Lighting Outputs 21W per side
Brake Light Output 42W total
Actuator Current:
- ISM 15A max at reduced speed. 12A max at full speed.
- SM 12A max.
Moisture Resistance: Electronics to IPX4
Non LCD Modules Modules with LCD Screens
Operating Temperature: -25°C to +50°C -10°C to +50°C
Storage Temperature: -40°C to +65°C -20°C to +65°C
EMC tested on sample wheelchair:
Susceptibility: Tested at 30V/m to EN12184 and ANSI/ RESNA requirements
Emissions: To EN55022 Class B
ESD: IEC801 part 2
