4.2.1 GENERAL
Fix the Power Module to the wheelchair chassis using suitable M5 or equivalent hardware.
4.2.2 ORIENTATION
The function of the Power Module is not sensitive to mounting orientation; however, it should be mounted in such a way that
water cannot enter and remain in the connector recesses. It is recommended that the unit is not mounted with the connectors
uppermost. The Power Module has an IPX4 moisture resistance rating.
4.2.3 POSITION
The Power Module must be mounted in a position where it is not exposed to conditions of water or dust above those specified
in ISO7176/9. The Power Module is designed to withstand levels of shock and vibration experienced when mounted to the
chassis of a wheelchair. Direct impacts onto the unit should be avoided.
4.3 ISM MOUNTING
