Example 2:
The front and rear LED clusters are of the same types and have voltage/current relationships as shown in the table below. The
values of Indicator XV Fault Current are calculated using:
Higher LED current + (Lower LED current / 2)
NOTE:
Any temperature or production tolerance in the LED cluster current draw must also be taken into account when determining
the fault current thresholds.
15 OEM FACTORY
The parameters within the OEM Factory group allow the manufacturer to set a maximum and minimum programming area for a
set of parameters. The set values create the new programmable range for the vehicles parameters which cannot be adjusted
without the R-net PC Programmer OEM level.
Example: A standard range for parameter X is 1% to 100%
The Absolute X parameter is set at 15% min to 75% max
This means that anyone wishing to change parameter X from now on ha s only got an available range of 15 to 75%.
WARNING:
It is the responsibility of the vehicle manufacturer, to ensure that adequate testing of the vehicle is carried out, to ensure
that the values set will maintain vehicle stability and user safety. Curtiss-Wright accepts no liability for losses of any kind
resulting from this parameter being incorrectly programmed.
