176 | R-net Technical Manual | Chapter 9 – Lighting Module (LM)
3 MOUNTING
3.1 GENERAL
The LM should be secured using four M5 screws with a maximum penetration of 7mm. Be careful not to over tighten the
screws.
3.1 ORIENTATION
The function of the LM is not sensitive to mounting orientation; however, it should be mounted in such a way that water canno t
enter and remain in the connector recesses. It is recommended that the unit is not mounted with the connectors uppermost.
The LM has an IPX4 moisture resistance rating.
3.2 POSITION
The LM must be mounted in a position where it is not exposed to conditions of water or dust above thos e specified in
ISO7176/9. The LM is designed to withstand levels of shock and vibration experienced when mounted to the chassis of a
wheelchair. Direct impacts onto the unit should be avoided.
