183 | R-net Technical Manual | Chapter 10 – Diagnostics
Curtiss-Wright | PG Drives Technology
3 DIAGNOSTIC TEXT DEFINITIONS
Once a trip text and module have been established use the following definitions to ascertain the possible cause and required
corrective procedure.
Trip Text
Referral Point
Center Joystick
Refer to section 3.1
Joystick Error
Refer to section 3.1
Low Battery
Refer to section 3.2
High Battery
Refer to section 3.3
M1 Brake Error
Refer to section 3.4
M2 Brake Error
Refer to section 3.4
M1 Motor Error
Refer to section 3.5
M2 Motor Error
Refer to section 3.5
Inhibit Active
Refer to section 3.6
Jstick Cal Error
Refer to section 3.7
Brake Lamp Short
Refer to section 3.8
Left Lamp Short
Refer to section 3.9
Right Lamp Short
Refer to section 3.9
L Ind Lamp Short
Refer to section 3.10
R Ind Lamp Short
Refer to section 3.10
L Ind Lamp Failed
Refer to section 3.11
R Ind Lamp Failed
Refer to section 3.11
Over-current
Refer to section 3.12
Overtemp. (Acts)
Refer to section 3.13
Overtemp. (Lamps)
Refer to section 3.14
DIME Error
Refer to section 3.15
Memory Error
Refer to section 3.16
PM Memory Error
Refer to section 3.17
Bad Cable
Refer to section 3.18
Bad Settings
Refer to section 3.19
Module Error
Refer to section 3.20
System Error
Refer to section 3.21
SID Detached
Refer to section 3.22
Switch Detached
Refer to section 3.23
Gone to Sleep
Refer to section 3.24
Charging
Refer to section 3.25
M1 Sensor Error
Refer to section 3.26
M2 Sensor Error
Refer to section 3.26
EM disconnected
Refer to section 3.26
JS Static Timeout
Refer to section 3.27
Orientation Error
Refer to section 3.28
ASM Disconnected
Refer to section 3.29
Gyro Disconnected
Refer to section 3.30
Gyro Prf Active
Refer to section 3.31
Switch Short
Refer to section 3.33
