39 | R-net Technical Manual | Chapter 2 - Installation
3 CONNECTIONS
The following is a selection of the most common configurations.
3.1 CONTROL CONFIGURATIONS
3.1.1 BASIC CONFIGURATION
Consists of a Power Module, a Communication Cable and a Joystick Module.
3.1.2 JOYSTICK & ISM CONFIGURATION
Consists of a Power Module, an Intelligent Seating/Lighting Module (ISM), 2 Communication Cables and a Joystick Module.
