D-Link DSR-1000 User Manual

D-Link DSR-Series User Manual 122
Section 7 - VPN
PPTP Client
Path: VPN > PPTP VPN > PPTP Client
PPTP VPN Client can be congured on this router. Using this client you can access remote network which is
local to PPTP server. Once client is enabled, the user can access Status > Active VPNs page and establish PPTP
VPN tunnel clicking Connect.
Field Description
Client Toggle to ON to enable PPTP client.
Server IP Enter the IP address of the PPTP server you want to connect to.
Remote Network Enter the remote network address. This address is local for the PPTP Server.
Remote Netmask Enter the remote network subnet mask.
Username
Enter your PPTP user name.
Password
Enter your PPTP password.
MPPE Encryption
Toggle to ON to enable Microsoft Point-to-Point Encryption (MPPE).
Idle Time Out
Enter the amount of time (in seconds) that you will disconnect from the PPTP server when idle.
Auto Connect Enable or disable the Auto Connect feature.
Time
Enter the reconnect time. If the client is disconnected from the server, then it will try to connect to the
server after the specied time.
Save Click Save to save and activate your settings.
To congure the router as a PPTP VPN client:
1. Click VPN > PPTP VPN > PPTP Client tab.
2. Toggle Client to ON and complete the elds in the table below.
Note: When the PPTP Client conguration is correctly saved and the PPTP server is up, the tunnel initiation starts
automatically.
