D-Link DSR-Ser
ies User Manual
20
Section 4 - LAN Conīguration
DHCP Relay
Field
Description
DHCP Mode
Select
DHCP Relay
from the drop-down menu.
Domain Name
Enter the domain name of your network.
Gateway
Enter the rela
y gateway IP address
.
Save
Click
Sa
ve
at the bottom to save and activate y
our settings.
2. Complete the īelds in the table belo
w and click
S
ave
.
1. Select
DHCP Relay
from the drop-down menu.
33
35
