xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
109
To view the following window, click L2 Features > L2 Multicast Control > IGMP Snooping > IGMP Snooping
Settings, as shown below:
Figure 4-42 IGMP Snooping Settings window
The fields that can be configured are described below:
Parameter Description
IGMP Snooping State
Click the radio buttons to enable or disable the IGMP Snooping state.
Max Learning Entry Value
(1-1024)
Enter the maximum learning entry value.
Click the Apply button to accept the changes made for each individual section.
Click the Edit button to configure the IGMP Snooping Parameters Settings.
Click the Modify Router Port link to configure the IGMP Snooping Router Port Settings.
After clicking the Edit button, the following page will appear:
Figure 4-43 IGMP Snooping Parameters Settings window
The fields that can be configured or viewed are described below:
Parameter Description
VID
Specify the name of the VLAN ID.
VLAN Name
Specify the name of the VLAN for which IGMP snooping querier is to be configured.
Rate Limit
Here is displayed the rate of IGMP control packets that the Switch can process on a
specific VLAN. The rate is specified in packet per second. The packets that exceed
the limited rate will be dropped.
