xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
260
Figure 8-54 BPDU Attack Protection window
The fields that can be configured are described below:
Parameter Description
BPDU Attack Protection
State
Click the radio buttons to enable or disable the BPDU attack protection state.
Trap State Specify when a trap will be sent. Options to choose from are None, Attack Detected,
Attack Cleared or Both.
Log State Specify when a log entry will be sent. Options to choose from are None, Attack
Detected, Attack Cleared or Both.
Recover Time
Specify the BPDU protection Auto-Recovery timer. The default value of the recovery
timer is 60.
Unit
Select the unit to configure.
From Port / To Port
Select a range of ports to use for this configuration.
State
Use the drop-down menu to enable or disable the protection mode for a specific port.
Mode
Specify the BPDU protection mode. The default mode is shutdown.
Drop – Drop all received BPDU packets when the port enters under attack state.
Block – Drop all packets (include BPDU and normal packets) when the port enters
under attack state.
Shutdown – Shut down the port when the port enters under attack state.
Click the Apply button to accept the changes made for each individual section.
Traffic Segmentation Settings
Traffic segmentation is used to limit traffic flow from a single or group of ports, to a group of ports. This method of
segmenting the flow of traffic is similar to using VLANs to limit traffic, but is more restrictive. It provides a method of
directing traffic that does not increase the overhead of the master switch CPU.
To view this window, click Security > Traffic Segmentation Settings, as shown below:
