xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
312
Figure 10-14 Ethernet OAM Settings window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit to configure.
From Port / To Port
Select a range of ports to be configured.
Mode Specify to operate in either Active mode or Passive mode The default mode is Active.
State Specify that the OAM function state is Enabled or Disabled. The default state is
Disabled.
Remote Loopback Specify to Start or Stop the OAM remote loopback function.
Received Remote
Loopback
Specify whether to Process or Ignore the received Ethernet OAM remote loopback
function. The default method is Ignore.
Click the Apply button to implement changes made.
Ethernet OAM Configuration Settings
This window is used to configure and display the primary controls and status information for Ethernet OAM on the
Switch.
To view this window, click OAM > Ethernet OAM > Ethernet OAM Configuration Settings, as shown below:
