xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
347
Figure 12-7 Download Configuration – TFTP window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Click the IPv4 or IPv6 radio button to enter the TFTP Server IP address.
File
Enter the location and name of the file.
Source File Enter the location and name of the source file, or click the Browse button to navigate to
the configuration file for the download.
Configuration ID
Select a configuration ID.
Click Download to initiate the download.
Upload Configuration File
This page allows the user to upload the configuration file from the Switch to a TFTP Server.
Open the Tools drop-down menu at the top of the Web manager and click Upload Configuration File to see the
following window:
Figure 12-8 Upload Configuration – TFTP window
