xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
285
Figure 9-4 DHCP Relay Interface Settings window
The fields that can be configured are described below:
Parameter Description
Interface Name
The IP interface on the Switch that will be connected directly to the server.
Server IP
Enter the IP address of the DHCP server. Up to four server IPs can be configured per IP
interface.
Click the Apply button to accept the changes made.
DHCP Relay VLAN Settings
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay VLAN Settings, as
shown below:
Figure 9-5 DHCP Relay VLAN Settings window
The fields that can be configured are described below:
Parameter Description
Server IP
Enter the IP address of the DHCP server. Up to four server IPs can be configured per
VLAN.
Action
Use the drop-down menu to add or delete the VLAN.
VID List
Enter a list of VLANs.
Click the Apply button to implement the changes made.
DHCP Relay Option 60 Server Settings
On this page the user can configure the DHCP relay option 60 server parameters.
To view this window, click Network Application > DHCP > DHCP Relay > DHCP Relay Option 60 Server
Settings, as shown below:
