xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
348
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Click the IPv4 or IPv6 radio button to enter the TFTP Server IP address.
File
Enter the location and name of the file.
Configuration ID
Select a configuration ID.
Filter Use the drop-down menu to include, begin or exclude a filter like SNMP, VLAN or STP.
Select the appropriate Filter action and enter the service name in the space provided.
Click Upload to initiate the upload.
Upload Log File
This page allows the user to upload the log file from the Switch to a TFTP Server.
Open the Tools drop-down menu at the top of the Web manager and click Upload Log File to see the following
window:
Figure 12-9 Upload Log File window
The fields that can be configured are described below:
Parameter Description
TFTP Server IP
Click the IPv4 or IPv6 radio button to enter the TFTP Server IP address.
File
Enter the location and name of the file.
To upload a history or attack log from the Switch to a TFTP server, enter a Server IP address, and file/path name
and then click Upload or Upload Attack Log.
To upload either a common log or an attack log by HTTP, click the desired Log Type in the bottom half of the
window and then click Upload.
Reset
The Reset function has several options when resetting the Switch. Some of the current configuration parameters
can be retained while resetting all other configuration parameters to their factory defaults.
