xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
169
HOL Blocking Prevention
HOL (Head of Line) Blocking happens when one of the destination ports of a broadcast or multicast packet are
busy. The Switch will hold this packet in the buffer while the other destination port will not transmit the packet even
they are not busy.
The HOL Blocking Prevention will ignore the busy port and forward the packet directly to have lower latency and
better performance.
On this page the user can enable or disable HOL Blocking Prevention.
To view the following window, click QoS > HOL Blocking Prevention, as shown below:
Figure 6-11 HOL blocking Prevention window
The fields that can be configured are described below:
Parameter Description
HOL Blocking Prevention
State
Click the radio buttons to enable of disable the HOL blocking prevention global
settings.
Click the Apply button to accept the changes made.
Scheduling Settings
QoS Scheduling
This window specifies the rotation mechanism regarding to the packets in the seven hardware priority queue are
being handled and emptied.
To view this window, click QoS > Scheduling Settings > QoS Scheduling, as shown below:
Figure 6-12 QoS Scheduling window
