Switch. When the Time-to-Live for an advertisement expires the advertised data is
then deleted from the neighbor Switch’s MIB.
LLDP ReInit Delay (1-10)
The LLDP re-initialization delay interval is the minimum time that an LLDP port will
wait before reinitializing after receiving an LLDP disable command. To change the
LLDP re-init delay, enter a value in seconds (1 to 10).
LLDP TX Delay (1-8192)
LLDP TX Delay allows the user to change the minimum time delay interval for any
LLDP port which will delay advertising any successive LLDP advertisements due to
change in the LLDP MIB content. To change the LLDP TX Delay, enter a value in
seconds (1 to 8192).
LLDP Notification
Interval (5-3600)
LLDP Notification Interval is used to send notifications to configured SNMP trap
receiver(s) when an LLDP change is detected in an advertisement received on the
port from an LLDP neighbor. To set the LLDP Notification Interval, enter a value in
seconds (5 to 3600).
Click the Apply button to accept the changes made for each individual section.
LLDP Port Settings
On this page the user can configure the LLDP port parameters.
To view the following window, click L2 Features > LLDP > LLDP > LLDP Port Settings, as shown below:
Figure 4-85 LLDP Port Settings window
The fields that can be configured are described below:
Parameter Description
Unit
Select a unit to configure.
From Port / To Port
Use the drop-down menu to select the ports used for this configuration.
Notification
Use the pull-down menu to enable or disable the status of the LLDP notification. This
function controls the SNMP trap. However, it cannot implement traps on SNMP when the
notification is disabled.
Admin Status
This function controls the local LLDP agent and allows it to send and receive LLDP
frames on the ports. This option contains TX, RX, TX and RX or Disabled.
TX - the local LLDP agent can only transmit LLDP frames.
