xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
123
Figure 4-60 MLD Router Port window
Enter a VID (VLAN ID) in the field at the top of the window.
Click the Find button to locate a specific entry based on the information entered.
Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.
NOTE: The abbreviations used on this page are Static Router Port (S), Dynamic Router Port (D)
and Forbidden Router Port (F).
MLD Snooping Group
Users can view MLD Snooping Groups present on the Switch. MLD Snooping is an IPv6 function comparable to
IGMP Snooping for IPv4.
To view the following window, click L2 Features > L2 Multicast Control > MLD Snooping > MLD Snooping
Group, as shown below:
Figure 4-61 MLD Snooping Group window
The fields that can be configured are described below:
Parameter Description
VLAN Name
Click the radio button and enter the VLAN name of the multicast group.
VID List
Click the radio button and enter a VLAN list of the multicast group.
Port List
Specify the port number(s) used to find a multicast group.
Group IPv6 Address
Enter the group IPv6 address used here. Select the Data Driven option to enable the
data driven feature for this MLD snooping group.
Data Driven
If Data Driven is selected, only data driven groups will be displayed.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear Data Driven button to delete the specific MLD snooping group which is learned by the Data Driven
feature of the specified VLAN.
Click the View All button to display all the existing entries.
