xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
153
Parameter Description
Network Address
Click the radio buttons and enter the network address.
IP Address
Click the radio buttons and enter the IP address.
Click the Find button to locate a specific entry based on the information entered.
IPv6 Static/Default Route Settings
A static entry of an IPv6 address can be entered into the Switch’s routing table for IPv6 formatted addresses.
To view the following window, click L3 Features > IPv6 Static/Default Route Settings, as shown below:
Figure 5-4 IPv6 Static/Default Route Settings window
The fields that can be configured are described below:
Parameter Description
IPv6 Address/Prefix
Length
The IPv6 address and corresponding Prefix Length of the IPv6 Static or Default Route
entry.
Interface Name
The IP Interface where the static IPv6 route is created.
Nexthop Address
The corresponding IPv6 address for the next hop Gateway address in IPv6 format.
Metric (1-65535)
The metric of the IPv6 interface entered into the table representing the number of
routers between the Switch and the IPv6 address above. Metric values allowed are
between 1 and 65535.
Backup State
Each IP address can only have one primary route, while other routes should be
assigned to the backup state. When the primary route fails, the Switch will try the
backup routes according to the order learned by the routing table until route success.
This field represents the backup state for the IPv6 configured. This field may be
Primary or Backup.
Click the Apply button to accept the changes made.
Click the Delete All button to remove all the entries listed.
IPv6 Route Table
This window displays the IPv6 route information.
