xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
310
Figure 10-11 CFM Packet Counter List window
The fields that can be configured are described below:
Parameter Description
Port List
Specify which ports’ counter to show. Tick All Ports to view all ports.
Type This drop-down menu allows you to select among Transmit, Receive and CCM.
Click the Find button to locate a specific entry based on the information entered.
Click the Clear button to clear all the information entered in the fields.
CFM Fault Table
This window is used to display the CFM Fault table on the Switch.
To view this window, click OAM > CFM > CFM Fault Table, as shown below:
Figure 10-12 CFM Fault Table window
The fields that can be configured are described below:
Parameter Description
MD Name
The Maintenance Domain Name.
MA Name
The Maintenance Association Name.
Click the Find button to show the information at the lower half of the window.
CFM MP Table
This window is used to display the CFM MP table on the Switch.
