xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
235
Figure 8-30 ND Snooping Maximum Entry Settings window
The fields that can be configured are described below:
Parameter Description
Unit
Select a unit to configure.
From Port / To Port
Use the drop-down menus to select a range of ports to use.
Maximum Entry (1-10)
Enter the maximum entry value. Tick the No Limit check box to have unlimited entries.
Click the Apply button to accept the changes made.
ND Snooping Entry
This window is used to display ND snooping status on specific ports.
To view this window, click Security > IP-MAC-Port Binding (IMPB) > ND Snooping > ND Snooping Entry, as
shown below:
Figure 8-31 ND Snooping Entry window
The fields that can be configured are described below:
Parameter Description
Port
Use the drop-down menu to select the desired port.
Ports (e.g.: 1:1, 1:7)
Specify the ports for which to view or clear ND snooping entries. Tick the All Ports check
box to view or clear entries for all ports.
Click the Find button to locate a specific entry based on the port number selected.
Click the Clear button to clear all the information entered in the fields.
Click the View All button to display all the existing entries.
