Dahua HCVR82**A-S3 Series User Manual

4
Parameters
HCVR8204A-S3
HCVR8208A -S3
HCVR8216A -S3
Audio Port
External Audio
Input
4-chanel RCA port
Coaxial Audio
Input
4-channel
8-channel
16-channel
Audio Output
1-channel RCA port. Output port reuses the bidirectional talk
output port.
Bidirectional
Talk Input
One independent audio talk input port.
Output port (RCA) reuses the audio output port.
Record
Record Mode
Schedule record/manual record/MD record/alarm record
Playback Mode
Instant playback, normal playback, event playback, mark
playback, smart playback
Record
Playback
Max 1/4/8/16-channel playback
Customized channel setup playback
Max 16-channel 1080P realtime playback or 1200W non realtime
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
16-channel alarm input
Alarm Output
3-channel output
HDD
HDD Port
2 SATA ports, one eSATA port
One HDD Space
8T
Communication
Port
Network
2 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS485 port, 1 RS232 port
USB
3 USB ports(One USB2.0 port at the front panel and two USB3.0
ports at the rear panel)
Others
Power
DC12V
Power
Consumption
≤25W
≤27W
≤32W
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
1U case，323mm（W）×375mm（D）×53mm（H）
Weight
≤2.30KG
≤2.35KG
≤2.45KG
Installation
Mode
Desk
1.3.2 HCVR84XXL-S3 Series
Parameters
HCVR8404L-S3
HCVR8408L -S3
HCVR8416L -S3
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
H.264H, H.264, H.264B
