Click Draw button to draw a zone. See Figure 4-154.
Figure 4-154
Name: Input customized rule name.
Period: System can generate an alarm once the object in the zone is missing for the specified
period.
Target filter: Click , you can set filter object size. Each rule can set two sizes (min size/max size).
Once the object is smaller than the min size or larger than the max size, there is no alarm. Please
make sure the max size is larger than the min size.
Now you can draw a rule. Left click mouse to draw a zone, until you draw a rectangle, you can right click
mouse.
Tips
Click to delete the corresponding rule.
Click , you can refer to the chapter 4.15.3.1 to set other parameters.
Click Apply to complete the setup.
4.15.4 Face Detection (Optional)
Important
Please connect to a smart network camera if you want to use face detection function.
Please make sure the connected smart network camera supports face detection function.
