Figure 4-46
4.4 Search Human Face (Optional)
Note
This function is for some series product only.
On the preview window, right click mouse and then select face search, or from the main menu, click
Face search, you can go to the following interface. See Figure 4-47.
Figure 4-47
Please refer to the following sheet for detailed information.
It is to display human face detection file list. The latest file is at the
bottom.
Click Export, you can export the selected file to the USB device.
There are two types: image/record.
Image: Export the recognized human face image.
Record: Export the record file before and after 10 seconds
when the DVR recognizes the human face.
Play the searched record file or image. Double click the file or click
button to playback.
Set date, start time and end time, click Search button, you can view the
corresponding file list.
