5.6.7.4.5 Calling AutoPan
Procedure
Step 1 On the expanded PTZ control panel, click to start moving in horizontal direction.
Step 2 Click again to stop moving.
5.6.7.4.6 Auxiliary Button
On the expanded PTZ control panel, click .
In the Shortcut Aux list, select the option that corresponds to the applied protocol.
In the Aux No. box, enter the number that corresponds to the AUX switch on the decoder.
Figure 5-44 Auxiliary
5.6.7.5 EPTZ
5.6.7.5.1 Conguring EPTZ Linkage
This function can simultaneously zoom in and track multiple humans and vehicles that trigger
alarms. It provides rich details and a panoramic view at the same time.
Procedure
Step 1 Right-click the live page, and then select Main Munu.
Step 2 Select CAMERA > EPTZ Linkage.
Step 3 Congure the parameters.
User's Manual
152
