No. Function No. Function
7 Network port 8 HDMI port
9
●
NVR608-4K: USB 2.0 port
●
NVR608-4KS2: USB 3.0 port
10 USB 3.0 port
11 eSATA port 12 Ground
2.2.28 NVR616-4KS2 Series
The general series rear panel of NVR616-4KS2 is shown as below.
Figure 2-89 Rear panel
The redundant power series rear panel of NVR616-4KS2 is shown as below.
Figure 2-90 Rear panel
User's Manual
63
