Name Function
channel data to the HDMI port of the display device. HDMI
version is 1.4.
VGA
VGA video
output port
VGA video output port. Output analog video signal. It can
connect to the monitor to view analog video.
PoE PORTS PoE port
Built-in Switch. Support PoE.
For PoE series product, you can use this port to provide
power to the network camera.
2.2.10 NVR21-W-4KS2 Series
Figure 2-63 Rear panel
Table 2-24 Ports
Port Name
Connection Function
USB 2.0 port
USB 2.0 port. Connect to mouse, USB storage
device, USB burner and more.
Network port
10/100 Mbps self-adaptive Ethernet port.
Connect to the network cable.
User's Manual
38
