The gure is for reference only.
Figure 2-7 Front panel
Table 2-4 Icons
Icon
Name Function
HDD HDD status indicator light
The blue light is on when the HDD
malfunctions.
NET Network status indicator light
The blue light is on when the network
connection is abnormal.
PWR Power status indicator light
The blue light is on when the power
connection is normal.
2.1.5 NVR21HS-W-4KS2/NVR11HS-W-S2-CE/NVR11HS-W-S2-FCC
Series
The front panel is shown as below.
