Dahua NVR2104-I2 User Manual

6.4.2 Main Device
Background Information
You can add several main devices manually. After you enable the cluster function, you can vie IP
address, working status and connection log of the main device.
Procedure
Step 1 Select SETTING > Cluster Service > Main Device.
Step 2 Click Manual Add.
Figure 6-2 Manual add
Step 3 Congure parameters.
Table 6-2 Parameters of adding main device
Parameter
Description
Device Name Customize the device name.
IP Address Enter the IP address of the NVR.
Port
Set the TCP port number of the server. The default value is 37777.
You can view the current TCP port number in SETTING > Network >
Port.
Username/Password Enter the username and password of the NVR.
Step 4 Click OK.
Step 5
(Optional) Click to view event occurrence time, name, operation and reason.
User's Manual
426
