Dahua NVR2104-I2 User Manual

Figure 2-9 Front panel
The NVR21-P-I/NVR21-P-I2 front panel is shown as below.
Figure 2-10 Front panel
The NVR21-8P-I/NVR21-8P-I2 front panel is shown as below.
Figure 2-11 Front panel
2.1.7 NVR22-I/NVR22-I2/NVR22-P-I/NVR22-P-I2/NVR22-8P-I/
NVR22-8P-I2/NVR22-16P-I/NVR22-16P-I2/NVR52-EI/NVR52-8P-
EI/NVR52-16P-EI/NVR41HS-EI/NVR42-EI/NVR41HS-P-EI/NVR42-P-
EI/NVR41HS-8P-EI/NVR42-8P-EI/NVR42-16P-EI/NVR44-EI/
NVR44-16P-EI
The gure is for reference only.
The NVR22-I/NVR22-I2 front panel is shown as below.
User's Manual
10
