Figure 2-12 Front panel
The NVR22-P-I/NVR22-P-I2 front panel is shown as below.
Figure 2-13 Front panel
The NVR22-8P-I/NVR22-8P-I2 front panel is shown as below.
Figure 2-14 Front panel
The NVR22-16P-I/NVR22-16P-I2 front panel is shown as below.
Figure 2-15 Front panel
The NVR52-EI/NVR52-8P-EI/NVR52-16P-EI/NVR54-EI/NVR54-16P-EI/NVR41HS-EI/NVR42-EI/NVR41HS-
P-EI/NVR42-P-EI/NVR41HS-8P-EI/NVR42-8P-EI/NVR42-16P-EI/NVR44-EI/NVR44-16P-EI front panel is
shown as below.
Figure 2-16 Front panel
Table 2-6 Icons
Icon
Name Function
HDD
HDD status indicator
light
The blue light is on when the HDD
malfunctions.
User's Manual
11
