2.2.6 NVR41-4KS2/NVR41-P-4KS2/NVR41-8P-4KS2/
NVR41-4KS2/L/NVR41-P-4KS2/L/NVR41-8P-4KS2/L/NVR21-S3/
NVR21-P-S3/NVR21-8P-S3
The NVR41-4KS2/NVR41-4KS2/L/NVR21-S3 series rear panel is shown as below.
Figure 2-50 Rear panel
The NVR41-P-4KS2/NVR41-P-4KS2/L series rear panel is shown as below.
Figure 2-51 Rear panel
The NVR41-8P-4KS2/NVR41-8P-4KS2/L series rear panel is shown as below.
Figure 2-52
Table 2-20 Ports
Port Name
Connection Function
USB port
USB port. Connect to mouse, USB storage device,
USB burner and more.
Network port
10/100 Mbps self-adaptive Ethernet port. Connect
to the network cable.
