Parameter Description
The default version is V3. There is a risk if you use V1 or V2.
SNMP Port Enter the monitoring port on the agent program.
Read Community
Enter the read and write strings supported by the agent program.
Write Community
Trap Address
Enter the destination address for the agent program to send the Trap
information.
Trap Port
Enter the destination port for the agent program to send the Trap
information.
Read-Only Username
Enter the username that is allowed to access the Device and has the read-
only permission.
Read/Write Username
Enter the username that is allowed to access the Device and has the read
and write permission.
Authentication Type Select MD5 or SHA. The system recognizes the type automatically.
Authentication
Password
Enter the password for authentication. The password should be no less
than eight characters.
Encryption Type Select an encryption type. The default setting is CBC-DES.
Encryption Password Enter the encryption password.
Step 4 Click Apply.
Step 5 Compile the two MIB îš‚les by MIB Builder.
Step 6 Run MG-SOFT MIB Browser to load in the module from compilation.
Step 7 On the MG-SOFT MIB Browser, enter the device IP that you want to manage, and then
select the version number to query.
Step 8 On the MG-SOFT MIB Browser, unfold the tree-structured directory to obtain the
conîš‚gurations of the Device, such as the channels quantity and software version.
5.11.14 Multicast
Background Information
When you access the Device from the network to view the video, if the access is exceeded, the
video will not display. You can use the multicast function to group the IP to solve the problem.
Procedure
Step 1 Select Main Menu > NETWORK > Multicast.
User's Manual
334
