2.2.5 NVR54-4KS2/NVR58-4KS2/NVR54-16P-4KS2/
NVR58-16P-4KS2/NVR54-24P-4KS2/NVR58-16P-4KS2E
The NVR54-4KS2/NVR58-4KS2 series rear panel is shown as below.
Figure 2-45 Rear panel
The NVR54-16P-4KS2/NVR58-16P-4KS2 series rear panel is shown as below.
Figure 2-46 Rear panel
The NVR54-24P-4KS2 series rear panel is shown as below.
Figure 2-47 Rear panel
The NVR54-16P-4KS2E series rear panel is shown as below.
Figure 2-48 Rear panel
The NVR58-16P-4KS2E series rear panel is shown as below.
